Stripe subscription billing architecture that survives webhooks

A reliable Stripe subscription integration has four parts: Stripe Checkout to start the subscription, a webhook endpoint that verifies and records every event, a background worker that re-reads the subscription from Stripe and updates your database, and an access check that reads only your database. Built this way, duplicate, late and out-of-order webhooks cannot leave a customer with the wrong access.

This article lays out that architecture for a typical SaaS, with TypeScript code type-checked against the official stripe Node.js library version 23 (which uses Stripe API version 2026-09-30.endive), and the subscription statuses and events you actually need to handle.

The architecture at a glance

Step 1: Model billing state in your own database

Keep a small, explicit copy of what Stripe knows. Three tables cover most products:

CREATE TABLE billing_customers (
  account_id          BIGINT PRIMARY KEY,
  stripe_customer_id  VARCHAR(255) NOT NULL UNIQUE
);

CREATE TABLE billing_subscriptions (
  stripe_subscription_id VARCHAR(255) PRIMARY KEY,
  stripe_customer_id     VARCHAR(255) NOT NULL,
  status                 VARCHAR(32)  NOT NULL,  -- trialing, active, past_due, canceled, unpaid, ...
  price_ids              JSON         NOT NULL,
  current_period_end     DATETIME     NULL,
  cancel_at_period_end   BOOLEAN      NOT NULL DEFAULT FALSE,
  updated_at             DATETIME     NOT NULL DEFAULT CURRENT_TIMESTAMP ON UPDATE CURRENT_TIMESTAMP,
  INDEX (stripe_customer_id)
);

CREATE TABLE stripe_events (
  event_id     VARCHAR(255) PRIMARY KEY,   -- the unique key is the de-duplication
  type         VARCHAR(100) NOT NULL,
  received_at  DATETIME     NOT NULL DEFAULT CURRENT_TIMESTAMP,
  processed_at DATETIME     NULL
);

Create the Stripe Customer when the account is created (or at first checkout) and store its ID. Linking by your own account ID avoids the classic bug of matching customers by email address, which breaks when someone changes their email or has two accounts.

Step 2: Start subscriptions with Checkout, manage them with the portal

Stripe-hosted Checkout handles card entry, Strong Customer Authentication and tax collection settings, and the Customer Portal handles plan changes, cancellations and card updates. That keeps card data out of your systems entirely.

import Stripe from 'stripe';

const stripe = new Stripe(process.env.STRIPE_SECRET_KEY!);

export async function startCheckout(customerId: string, priceId: string, accountId: string) {
  const session = await stripe.checkout.sessions.create({
    mode: 'subscription',
    customer: customerId,                 // create the Customer once, at sign-up
    line_items: [{ price: priceId, quantity: 1 }],
    client_reference_id: accountId,       // your own account ID, echoed back in the event
    success_url: 'https://app.example.com/billing?checkout=success',
    cancel_url: 'https://app.example.com/billing?checkout=cancelled',
  });
  return session.url;
}

export async function openBillingPortal(customerId: string) {
  const portal = await stripe.billingPortal.sessions.create({
    customer: customerId,
    return_url: 'https://app.example.com/billing',
  });
  return portal.url;
}

The success page should only say "we are confirming your payment". Access is granted when the webhook pipeline updates your database, usually within seconds.

Step 3: A webhook endpoint that verifies, records and returns

Stripe's webhook documentation sets three rules: verify that each event comes from Stripe using the Stripe-Signature header and your endpoint's whsec_ secret; use the raw request body, because any change to it breaks verification; and return a 2xx quickly, before any complex logic that could time out. It also recommends handling events through an asynchronous queue, because renewals cluster (for example, at the start of the month).

import express from 'express';
import Stripe from 'stripe';

const stripe = new Stripe(process.env.STRIPE_SECRET_KEY!);
const endpointSecret = process.env.STRIPE_WEBHOOK_SECRET!;

// Your persistence and queue; implement against your own database.
declare const db: {
  recordEventOnce(eventId: string, type: string): Promise<boolean>; // false if already seen
};
declare const jobs: { add(name: string, data: { eventId: string }): Promise<void> };

const app = express();

// The raw body is required for signature verification, so this route
// must be registered before any global express.json() middleware.
app.post('/webhooks/stripe', express.raw({ type: 'application/json' }), async (req, res) => {
  let event: Stripe.Event;
  try {
    event = stripe.webhooks.constructEvent(req.body, req.header('stripe-signature') ?? '', endpointSecret);
  } catch (err) {
    res.status(400).send(`Webhook signature verification failed: ${(err as Error).message}`);
    return;
  }

  // Store the event ID once; duplicates are acknowledged and ignored.
  if (await db.recordEventOnce(event.id, event.type)) {
    await jobs.add('stripe-event', { eventId: event.id });
  }
  res.sendStatus(200); // acknowledge fast; the worker does the real work
});

app.use(express.json()); // other routes

app.listen(4242);

We tested the verification step locally: a signature generated over the exact bytes verified, while the same JSON re-serialised with different whitespace was rejected with StripeSignatureVerificationError. That is what happens when a global express.json() middleware runs before the webhook route, and it is the most common reason webhooks fail on first deploy. The libraries also reject signatures older than a default tolerance of five minutes to prevent replay attacks, so keep server clocks in sync with NTP.

Step 4: A worker that converges on the truth

Stripe states plainly that events are not guaranteed to arrive in order and that an endpoint may occasionally receive the same event more than once. Creating a subscription can produce customer.subscription.created, invoice.created, invoice.paid and charge.created in any order. Stripe advises tracking event IDs to spot duplicates and not using the event's created timestamp for ordering.

The simplest robust design ignores the event payload's snapshot and treats each event as a signal: "something changed on subscription X". The worker fetches the subscription's current state from the API and overwrites your row. Processing the same event twice, or an old event after a new one, produces the same final state.

import Stripe from 'stripe';

const stripe = new Stripe(process.env.STRIPE_SECRET_KEY!);

declare const db: {
  upsertSubscription(row: {
    stripeSubscriptionId: string;
    stripeCustomerId: string;
    status: Stripe.Subscription.Status;
    priceIds: string[];
    currentPeriodEnd: Date | null;
    cancelAtPeriodEnd: boolean;
  }): Promise<void>;
};

const HANDLED = new Set([
  'checkout.session.completed',
  'customer.subscription.created',
  'customer.subscription.updated',
  'customer.subscription.deleted',
  'invoice.paid',
  'invoice.payment_failed',
]);

// Runs in a background worker. Re-fetches current state instead of trusting
// event order, so duplicate or out-of-order events converge on the truth.
export async function processStripeEvent(eventId: string): Promise<void> {
  const event = await stripe.events.retrieve(eventId);
  if (!HANDLED.has(event.type)) return;

  const subscriptionId = subscriptionIdFrom(event);
  if (!subscriptionId) return;

  const sub = await stripe.subscriptions.retrieve(subscriptionId);
  const periodEnds = sub.items.data.map((item) => item.current_period_end);
  await db.upsertSubscription({
    stripeSubscriptionId: sub.id,
    stripeCustomerId: typeof sub.customer === 'string' ? sub.customer : sub.customer.id,
    status: sub.status,
    priceIds: sub.items.data.map((item) => item.price.id),
    currentPeriodEnd: periodEnds.length ? new Date(Math.max(...periodEnds) * 1000) : null,
    cancelAtPeriodEnd: sub.cancel_at_period_end,
  });
}

function subscriptionIdFrom(event: Stripe.Event): string | null {
  const obj = event.data.object as unknown as Record<string, unknown>;
  if (event.type.startsWith('customer.subscription.')) return obj.id as string;
  if (event.type === 'checkout.session.completed') {
    const s = obj.subscription;
    return typeof s === 'string' ? s : null;
  }
  if (event.type.startsWith('invoice.')) {
    const invoice = event.data.object as Stripe.Invoice;
    const s = invoice.parent?.subscription_details?.subscription;
    return typeof s === 'string' ? s : (s?.id ?? null);
  }
  return null;
}

export const hasAccess = (status: Stripe.Subscription.Status) =>
  status === 'active' || status === 'trialing';

Two details reflect recent API versions. Since 2025-03-31.basil, the billing period lives on each subscription item (items.data[].current_period_end) rather than on the subscription, and an invoice points to its subscription through parent.subscription_details.subscription. Code written against older API versions breaks on both.

Step 5: Decide access from subscription status

Stripe's subscription statuses map to access decisions like this:

Stripe's own guidance is to revoke access when a subscription becomes canceled or unpaid, to notify the customer when it becomes past_due, and, after invoice.paid, to confirm the subscription is active before extending access. If you offer a grace period for past_due, make it an explicit product rule with a fixed number of days.

The events worth subscribing to

• checkout.session.completed: links the new subscription to your account via client_reference_id.
• customer.subscription.created, .updated, .deleted: status, plan and cancellation changes, including those made in the portal.
• invoice.paid and invoice.payment_failed: renewals succeeded or failed; send your own emails here if you want them.
• customer.subscription.trial_will_end: sent three days before a trial ends; check that a payment method exists.
• invoice.payment_action_required: the customer must authenticate a payment.
• charge.dispute.created and charge.refunded: decide whether disputes or refunds should affect access.

Stripe recommends subscribing only to the events you need. If you listen to invoice.created, respond to it promptly: if Stripe does not get a successful response, it delays finalising automatically collected invoices for up to 72 hours.

Testing before you go live

The Stripe CLI forwards real sandbox events to your laptop and can trigger them on demand:

stripe login
stripe listen --forward-to localhost:4242/webhooks/stripe
# in another terminal
stripe trigger customer.subscription.created
stripe trigger invoice.payment_failed

stripe listen prints a temporary signing secret; use it as STRIPE_WEBHOOK_SECRET locally. Then walk a sandbox subscription through trial end, a failed renewal and a card update before launch.

Gotchas

• Failing endpoints are retried, then you are emailed. In live mode Stripe retries delivery for up to three days with exponential back-off; in a sandbox it retries three times over a few hours. Monitor your endpoint's error rate rather than relying on retries.
• Redirects count as failures. A 301 from http to https or from a trailing slash fails delivery. Register the exact final URL.
• CSRF middleware blocks webhooks. Exempt the webhook route; the signature is its authentication.
• One endpoint secret per endpoint and mode. Test and live endpoints have different secrets; roll them periodically from Workbench.
• Webhooks are not a substitute for reconciliation. Run a nightly job that lists recently updated subscriptions from the API and repairs any row that drifted.

What to do next

1. Add the three tables and the access check, and route every "is this account paid?" decision through it.
2. Move your webhook route above any JSON body parser and add signature verification if it is missing.
3. Put event processing on your existing job queue and make it re-fetch state from Stripe.
4. Write down your past_due grace rule and dunning emails before the first failed renewal arrives.
