Fix PHP-FPM 'server reached pm.max_children' and 502 errors

When PHP-FPM logs server reached pm.max_children setting, every worker in the pool is busy and new requests wait in a queue. Users see slow pages, then 504 Gateway Timeout or 502 Bad Gateway errors from Nginx. The fix is not to raise the number blindly: measure how much memory a worker uses, size pm.max_children to the RAM you have, and find the slow requests that keep workers busy.

We reproduced the problem on PHP 8.5.7 with a deliberately tiny pool, and every log line and status field below comes from that run.

What the warning means

PHP-FPM runs a fixed maximum number of worker processes per pool. Each worker handles one request at a time. The manual describes pm.max_children as the limit on simultaneous requests that will be served. When all workers are active and another request arrives, FPM logs a warning and the request waits for a free worker.

We configured a pool with pm.max_children = 2 and sent four requests to a script that sleeps for 2.5 seconds. The error log showed:

WARNING: [pool demo] server reached pm.max_children setting (2), consider raising it
WARNING: [pool demo] child 91338, script '/srv/www/slow.php' (request: "GET /slow.php") executing too slow (1.005765 sec), logging

The first line is the capacity problem. The second comes from the slow log, which we enabled with request_slowlog_timeout = 1s. Together they tell the usual story: requests are slow, so workers stay busy, so the pool runs out.

How this turns into 502 and 504 errors

Queued requests are not lost straight away. Nginx waits for a response for fastcgi_read_timeout, which defaults to 60 seconds. If the request is still waiting or running after that, Nginx returns 504. A 502 usually means Nginx could not talk to FPM at all: the socket path is wrong, FPM is down, a worker was killed mid-request (for example by request_terminate_timeout or the kernel's out-of-memory killer), or the connection queue was full.

Step 1: read the status page

Enable the built-in status page in the pool with pm.status_path = /fpm-status and expose it to localhost only:

location = /fpm-status {
    allow 127.0.0.1;
    deny all;
    include fastcgi_params;
    fastcgi_param SCRIPT_NAME /fpm-status;
    fastcgi_pass unix:/run/php/php8.5-fpm.sock;
}

During our test the status page reported these fields (trimmed):

pool:                 demo
process manager:      dynamic
accepted conn:        5
listen queue:         0
max listen queue:     0
idle processes:       0
active processes:     2
total processes:      2
max active processes: 2
max children reached: 1
slow requests:        4

Add ?full to see each worker's state, request URI, duration (in microseconds), CPU and memory for its last request. Add ?json, ?xml, ?html or ?openmetrics to feed a monitoring system. The ping.path setting gives a simpler health check that answers pong, which we confirmed in our test.

curl -s 'http://127.0.0.1/fpm-status?json'
curl -s 'http://127.0.0.1/fpm-status?full'

Step 2: size pm.max_children from memory

Every worker is a separate process with its own memory. The safe maximum is the memory you can give PHP divided by the memory a typical worker uses. Measure the average under real traffic:

# Average resident memory per worker, in MB (Linux; adjust the process name)
ps --no-headers -o rss -C php-fpm8.5 | awk '{ sum += $1; n++ } END { printf "%.0f MB avg over %d processes\n", sum / n / 1024, n }'

A worked example: a server with 4 GB of RAM runs Nginx and PHP-FPM, while the database lives elsewhere. Reserve about 1 GB for the operating system, Nginx and OPcache shared memory, leaving roughly 3 GB. If workers average 80 MB, then 3072 / 80 is about 38, so set pm.max_children = 35 to keep a margin. If workers average 200 MB, the same server supports only about 15.

Raising pm.max_children beyond what memory allows trades a queue for swapping or the out-of-memory killer, which is worse. If the arithmetic gives too few workers, reduce per-request memory, move heavy work to a queue or add servers.

Step 3: choose the process manager mode

The pm directive is mandatory and accepts three values:

In dynamic mode, pm.start_servers defaults to the midpoint of the two spare settings, and pm.max_spawn_rate (default 32) limits how many workers FPM creates at once during a burst.

Step 4: find what keeps workers busy

A pool that runs out of workers is usually a symptom of slow requests. A request that takes 10 seconds holds a worker ten times longer than one that takes one second. Turn on the slow log:

• request_slowlog_timeout (default 0, off) dumps a PHP backtrace to the slowlog file for any request that runs longer than the value.
• request_terminate_timeout (default 0, off) kills a worker whose request runs longer than the value. The manual suggests it for cases where max_execution_time does not stop a script, for example while it waits on external calls.

Writing the backtrace requires the FPM master to trace the worker. In our macOS test the slow requests were detected and counted, but tracing failed with an insufficient privileges error, so the slow log file stayed empty. On Linux containers you may hit the same limit if ptrace is restricted. Check the slow log file after enabling it, not just the counter.

Common causes found in slow logs are external HTTP calls without timeouts, unindexed database queries, sessions locked by long requests, and report generation or image processing done inside the web request.

A balanced pool configuration

This is a reasonable starting point for the 4 GB example above. Adjust pm.max_children to your own measurement.

; /etc/php/8.5/fpm/pool.d/www.conf  (path varies by distribution)
[www]
listen = /run/php/php8.5-fpm.sock

pm = dynamic
pm.max_children = 35
pm.start_servers = 8
pm.min_spare_servers = 4
pm.max_spare_servers = 12
pm.max_requests = 1000

pm.status_path = /fpm-status
ping.path = /ping

request_slowlog_timeout = 5s
slowlog = /var/log/php-fpm/$pool.slow.log
request_terminate_timeout = 60s

pm.max_requests = 1000 recycles each worker after a thousand requests, which the manual describes as a workaround for memory leaks in third-party libraries. The default of 0 never recycles workers.

Gotchas

• Several pools share one machine. Add up pm.max_children across all pools before comparing with available memory.
• Status page exposed publicly. It reveals request URIs and timings; restrict it to localhost or your monitoring network.
• Timeouts that do not line up. If request_terminate_timeout is longer than Nginx's fastcgi_read_timeout, users get a 504 while the worker keeps running. Keep the FPM limit equal to or shorter than the proxy limit.
• Restarting instead of reloading. Prefer a graceful reload after config changes so in-flight requests finish. The global process_control_timeout sets how long workers get to react to the master's signals.
• Crash loops. The global emergency_restart_threshold and emergency_restart_interval restart FPM if too many workers die with SIGSEGV or SIGBUS in a short time.

What to do next

Enable the status page and slow log on one server today. Watch max children reached and slow requests for a few days of real traffic, measure worker memory, then set pm.max_children from the arithmetic rather than from a forum post. Fix the slowest endpoints in the slow log first: shorter requests free workers faster than any configuration change.
