Headless WordPress architecture: REST API, WPGraphQL and Next.js

Headless WordPress means using WordPress only as the content back end, while a separate front end, typically a Next.js app, fetches content through the built-in REST API or the WPGraphQL plugin and renders the pages. It makes sense when the same content feeds several front ends or when your team already ships a JavaScript application; for an ordinary marketing site or blog, a traditional block theme is usually cheaper and faster to run.

This guide covers the decision, a reference architecture that holds up in production, the content model code you need in WordPress, and the cache invalidation that most first headless projects get wrong. Versions are current as of October 2026: WordPress 7.1.3, WPGraphQL 2.23.1 and Next.js 16.4.

Should you go headless?

The last row is the real cost. In a traditional site, WordPress plugins produce meta tags, sitemaps, redirects, forms and previews for free. Headless, each one becomes front-end work.

A reference architecture

1. WordPress (the CMS) on its own hostname such as cms.example.com, used by editors and by the front end's server. Keep wp-admin behind your usual hardening.
2. Content API: the core REST API under /wp-json/wp/v2/, or GraphQL at /graphql with WPGraphQL.
3. Front end: a Next.js app that fetches on the server, caches responses and renders HTML. Visitors never call WordPress directly.
4. Cache invalidation: WordPress sends a signed webhook when content changes, and the front end refreshes only the affected data.
5. Media: images served from WordPress uploads or an object store behind a CDN, referenced by URL in API responses.

Step 1: Model content so the API exposes it

Custom post types, taxonomies and meta are invisible to the REST API unless you opt in. The handbook's rule is simple: set show_in_rest when registering, and optionally change rest_base for a nicer URL. Registered meta also needs show_in_rest, and the post type must support custom-fields or the meta will not appear.

<?php
/**
 * Plugin Name: Acme Content Model
 * Description: Event post type, taxonomy and meta for a headless front end.
 * Version:     1.0.0
 */

add_action( 'init', 'acme_register_content_model' );

function acme_register_content_model() {
	register_post_type(
		'event',
		array(
			'labels'              => array(
				'name'          => __( 'Events', 'acme' ),
				'singular_name' => __( 'Event', 'acme' ),
			),
			'public'              => true,
			'has_archive'         => true,
			'menu_icon'           => 'dashicons-calendar-alt',
			'supports'            => array( 'title', 'editor', 'excerpt', 'thumbnail', 'custom-fields' ),
			'show_in_rest'        => true,        // Adds /wp-json/wp/v2/events.
			'rest_base'           => 'events',
			'show_in_graphql'     => true,        // Read by WPGraphQL when active.
			'graphql_single_name' => 'event',
			'graphql_plural_name' => 'events',
		)
	);

	register_taxonomy(
		'event_type',
		'event',
		array(
			'labels'       => array( 'name' => __( 'Event types', 'acme' ) ),
			'hierarchical' => true,
			'show_in_rest' => true,
			'rest_base'    => 'event-types',
		)
	);

	register_post_meta(
		'event',
		'event_start',
		array(
			'type'              => 'string',
			'description'       => 'Start date and time, ISO 8601.',
			'single'            => true,
			'show_in_rest'      => true,
			'sanitize_callback' => 'sanitize_text_field',
			'auth_callback'     => static function () {
				return current_user_can( 'edit_posts' );
			},
		)
	);
}

Ship this as a plugin, not inside a theme: in a headless setup the theme is barely used, and content types must survive a theme change. For array or object meta, show_in_rest must be an array with a JSON Schema, including items for arrays.

Step 2: Fetch only what each page needs

The REST API supports global parameters that keep responses small. _fields limits the properties returned, and WordPress skips the work for fields you did not ask for. _embed includes linked resources such as the featured image or terms, and since WordPress 5.4 you can name which ones.

# Latest 20 events, only the fields the listing page uses
curl "https://cms.example.com/wp-json/wp/v2/events?per_page=20&_fields=id,slug,title,excerpt,meta.event_start"

# One event with its featured image and terms embedded
curl "https://cms.example.com/wp-json/wp/v2/events?slug=launch-night&_embed=wp:featuredmedia,wp:term"

Collections are paginated: per_page accepts 1 to 100, and the X-WP-Total and X-WP-TotalPages headers tell you how many records and pages exist.

With WPGraphQL active, the same model is available as a typed schema. A listing query looks like this:

query LatestEvents {
  events(first: 20) {
    nodes {
      databaseId
      slug
      title
      excerpt
    }
  }
}

WPGraphQL does not expose registered meta automatically; you add fields with its own registration API or an extension.

REST API or WPGraphQL?

A practical rule: start with REST for simple content sites; choose GraphQL when pages combine many related types and the team already uses GraphQL tooling.

Step 3: Cache in Next.js and invalidate on publish

In the Next.js App Router, fetch on the server with a revalidation window and cache tags:

// lib/wordpress.js
const API = process.env.WORDPRESS_API_URL; // e.g. https://cms.example.com/wp-json

export async function getEvents() {
  const url = `${ API }/wp/v2/events?per_page=20&_fields=id,slug,title,excerpt,meta.event_start`;
  const res = await fetch( url, { next: { revalidate: 3600, tags: [ 'events' ] } } );
  if ( ! res.ok ) {
    throw new Error( `WordPress responded with ${ res.status }` );
  }
  return {
    items: await res.json(),
    total: Number( res.headers.get( 'X-WP-Total' ) ),
  };
}

An hour-long window alone means edits can take an hour to appear. Fix that with a webhook. On the WordPress side, notify the front end when an event is published, updated or unpublished:

add_action( 'transition_post_status', 'acme_notify_frontend', 10, 3 );

function acme_notify_frontend( $new_status, $old_status, $post ) {
	if ( 'event' !== $post->post_type || ! defined( 'ACME_REVALIDATE_URL' ) || ! defined( 'ACME_REVALIDATE_SECRET' ) ) {
		return;
	}
	if ( 'publish' !== $new_status && 'publish' !== $old_status ) {
		return; // Drafts changing do not affect the public site.
	}

	wp_remote_post(
		ACME_REVALIDATE_URL,
		array(
			'blocking' => false,
			'timeout'  => 2,
			'headers'  => array(
				'Content-Type'        => 'application/json',
				'X-Revalidate-Secret' => ACME_REVALIDATE_SECRET,
			),
			'body'     => wp_json_encode( array( 'tags' => array( 'events', 'event-' . $post->ID ) ) ),
		)
	);
}

Define both constants in wp-config.php, never in code you commit. On the Next.js side, a route handler checks the secret and marks the tags stale:

// app/api/revalidate/route.js
import { revalidateTag } from 'next/cache';
import { timingSafeEqual } from 'node:crypto';

export async function POST( request ) {
  const given = Buffer.from( request.headers.get( 'x-revalidate-secret' ) ?? '' );
  const expected = Buffer.from( process.env.REVALIDATE_SECRET ?? '' );
  if ( expected.length === 0 || given.length !== expected.length || ! timingSafeEqual( given, expected ) ) {
    return Response.json( { error: 'Unauthorized' }, { status: 401 } );
  }

  const { tags = [] } = await request.json();
  for ( const tag of tags.filter( ( t ) => typeof t === 'string' ).slice( 0, 10 ) ) {
    revalidateTag( tag, 'max' );
  }
  return Response.json( { revalidated: true } );
}

Next.js 16 expects the two-argument form of revalidateTag(); the single-argument form is deprecated. The 'max' profile serves the cached page while fresh data loads in the background.

Authentication and security

• Public content needs no credentials. Fetch published posts anonymously, and keep it that way so a leaked front-end secret cannot read drafts.
• Drafts and previews need authentication. Since WordPress 5.6, Application Passwords provide Basic authentication over HTTPS. Create one for a dedicated low-privilege user and keep it in server-side environment variables only.
• Cookie authentication with nonces only works inside WordPress itself, so it is not an option for a separate front end.
• Do not expose more than you need. Meta registered with show_in_rest is public on published posts; keep internal fields unregistered or protected.

Gotchas

• Block markup needs block styles. content.rendered contains HTML with core block classes. Load the block library styles in the front end or map blocks to your own components.
• SEO plugins stop working on their own. Titles, canonical URLs, Open Graph tags and sitemaps must be rebuilt in the front end, usually from data the SEO plugin exposes over the API.
• Previews are a project. Plan an authenticated preview route early; editors notice its absence on day one.
• Permalinks and redirects. Keep slugs identical to the old site and port redirects, or you will lose search traffic.
• Two systems to patch. You now update WordPress, its plugins, Node.js and the framework. Budget for both.

What to do next

1. Write down every front-end feature your current plugins provide and decide who rebuilds each one.
2. Register your content model in a plugin with show_in_rest and test it at /wp-json/wp/v2/.
3. Build one listing page and one detail page with _fields, cache tags and the revalidation webhook.
4. Add authenticated previews before inviting editors.
5. Compare page speed and editorial effort with the theme-based site before committing fully.
